The accuracy and quality of the Norbar Static Torque Transducers has made them the first choice of many calibration laboratories throughout the world.

• Up to 5000 N·m (5000 lbf·ft) classified to BS7882:2008, typically better than Class 1 for the primary classification range (+/-0.5% of reading from 20% to 100% of full scale).
• Robust, heat treated, alloy steel torsion shaft design.
• Designed to ignore non torsional forces.
• Operates in clockwise and anti-clockwise directions.
• Calibration up to 100,000 N·m with a UKAS accredited Certificate.
• Calibrated in clockwise direction as standard. Anti-clockwise provided on request.
• 'SMART' transducers have a built in memory circuit which contains essential information about the transducer. This information can be read by Norbar's TST, TTT, TTL-HE & T-Box instruments meaning that when the transducer is connected, it is immediately recognised and ready for use.
• 'SMART' transducers can also be used with many other instruments. However, these will operate as normal ratio calibrated (mV/V) transducers - the 'SMART' data will not be read.

For non Norbar instruments or for when a mV/V certificate is required, use part code suffix ‘.IND’.

S.I Calibrated Transducers

*Not suitable for TST and TTT.
Select part no. suffix .LOG if the transducer is to be connected to TST or TTT (example: 50588.LOG). For connection to a non Norbar instrument or when a mV/V cer tif icate is required, select .IND
